Description

 **CALL FOR AVAILABILITY**

B or Class A wiring.

The SLC-PM supports the following devices:

• Up to 318 System Sensor Velociti® devices.

– 159 sensors and 159 modules.

• Up to 198 System Sensor CLIP devices.

– 99 sensors and 99 modules.

The SLC95-PM supports the following devices:

• Up to 126 Apollo XP95 devices.

– 126 sensors and modules.

Installation

The SLC-PM/SLC95-PM  are designed to be

plugged into the Smart Loop Panel-Main Board (SLP-E3).

This feature allows you to expand the S3 Series System

without the need to remove or replace hardware.

Specifications

SLC-PM SLC95-PM

Operating Current: 0.014 amp 0.016 amp

Alarm Current: 0.014 amp 0.016 amp

Line Impedance: 40 Ohms

Line Capacitance: 0.5 ?f max.

Operating Voltage: 24 VDC FWR

Operating Temperature: 32° to 120° F (0° to 49° C)

Relative Humidity: 0 to 93%,non-condensing at 90° F
